Vacuum Sintering Furnace
BRAZ_V
SPECIFICATIONS
| Process | Brazing Metal annealing Vacuum diffusion Sintering |
|---|---|
| Chamber material | SUS304 |
| Heating element | Graphite heater |
| Substrate heater temperature | 1,350℃ |
| Heating zone | 48L (326mm(W)*326mm(D)*450mm(H)) |
| Cooling zone | Cool down rate : 1,100℃→200℃ / 20min |
| Ultimate pressure | < 5.0×10-6 Torr |
| Pump | Diffusion + Rotary pump |
| Loading & cooling chamber | |
| Gas Supply | Ar (extensible) |
| Temperature uniformity | < ±3℃ @1,000℃ |
| System control | PC control (full auto) |
| Dimension (w*d*h) | 2,000mm*650mm*1,400mm |
